TVN 3-0922
3 Watt DC/DC convertr, industrial, 2:1 input, ultra low ripple & noise, 1600 VDC isolation, encapsulated, metal case, SIP-8 package
Availability: Out of Stock
Package Type: SIP-8
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the TVN 3-0922 by Traco Power and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the TVN 3-0922
| Part Name | TVN 3-0922 |
| Manufacturer | Traco Power |
| Category | Power Products |
| Number of Outputs | dual |
| Product Width | 9.6 |
| GTIN | 7613441060842 |
| Mounting Type | PCB Mount |
| Adjustable output? | No |
| Isolation Voltage Input and Output (V) | 1600 VDC |
| Power | 3.0 |
| Insulation System | Functional Insulation |
| REACH | Yes |
| Product Height | 11.2 |
| Efficiency | 82.0 |
| Compatible Accessories | TCK-151 |
| Housing Type | Metal Case |
| Remote on-off function? | Yes |
| Product Length | 21.8 |
| ESD Sensitive | No |
| Iout | 125/125 |
| Warranty Period | 3-year |
| Temperature Range Max. | 90 |
| Comformity | https://www.tracopower.com/ch/conformity-regulatory |
| Footprint Type | SIP8 |
| RoHS | Yes |
| Vout | ±12 |
| Family | DC/DC Converter isolated, regulated |
| Series Name | TVN 3 |
| Lifecycle Status | Active |
| Vin | 4.5-13.2 |
| high_runner | TRUE |
| Weight | 5.9 |
| Temperature Range Min. | -40 |
| Connection Type | THD (Through-Hole Device) |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the TVN 3-0922
