7443551130
SnapVerified
1.3 µH Shielded Wirewound Inductor 25 A 1.8mOhm Nonstandard
Availability: In Stock
Package Type: NONSTANDARD
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 7443551130 by Wurth Electronics and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 7443551130
| Part Name | 7443551130 |
| Manufacturer | Wurth Electronics |
| Product Series Size | 1365 |
| Division | Passive Components, Power Modules, Optoelectronics |
| Article Description Long | Size 1365; L = 1.3 µH ±20%; IR = 25 A; Isat = 25 A; RDC = 1.8 mΩ |
| Product Family | Single Coil Power Inductors |
| Weight | 5.1072 |
| Ro Hs Approval | 2011/65/EU&2015/863 |
| Rated Current (A) | 25 |
| Spq | 400 |
| Current Revision (A) | 7.1.0 |
| Packaging Type | 13''Reel |
| Height | 6.2 mm |
| Reach Approval | Conform or declared |
| Width | 12.8 mm |
| Length | 13.2 mm |
| Product Unit | eiSos |
| Product Group Description | Power Magnetics |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
